صفحه نمایش LED سه بعدی چشم برهنه
-
معرفی
معرفی
Our Naked eye 3D LED screen is a revolutionary display solution that is taking the global market by storm. By leveraging advanced optical technologies such as parallax barrier and lenticular lens, this screen creates a stunning three - dimensional visual experience without the need for viewers to wear any special glasses.
مورد |
FC3.33 |
FC4.44 |
FC5.7 |
FC6.67 |
FC8 |
FC10 |
ترکیب نقاط |
SMD1415 |
SMD1921 |
SMD2727 |
SMD2727 |
SMD2727 |
SMD2727 |
پیکسل پیچ (میلی متر) |
3.33 |
4.44 |
5.7 |
6.67 |
8 |
10 |
وضوح ماژول (W × H) |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
اندازه ماژول (میلی متر) |
480 × 320 × 14 |
480 × 320 × 14 |
480 × 320 × 14 |
480 × 320 × 14 |
480 × 320 × 14 |
480 × 320 × 14 |
وضوح کابینت (W × H) |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
۱۳۰۰ × ۶۰۰ |
حجم کابینه (میلی متر) |
960 × 960 × 84 |
960 × 960 × 84 |
960 × 960 × 84 |
960 × 960 × 84 |
960 × 960 × 84 |
960 × 960 × 84 |
وزن کابینت (کیلوگرم/کابینت) |
25 |
25 |
25 |
25 |
25 |
25 |
کابینه مواد |
آلومینیوم ریخته گری قالب |
آلومینیوم ریخته گری قالب |
آلومینیوم ریخته گری قالب |
آلومینیوم ریخته گری قالب |
آلومینیوم ریخته گری قالب |
آلومینیوم ریخته گری قالب |
تراکم کابینت(dot/m²) |
90000 |
50625 |
30625 |
22500 |
15625 |
10000 |
IP رتبه |
IP68 |
IP68 |
IP68 |
IP68 |
IP68 |
IP68 |
روشنایی تراز سفیدی (nits) |
≥ 4500 |
≥ 5000 |
≥ 5000 |
≥ 5500 |
≥ 6000 |
≥ 6000 |
دمای رنگ (K) |
6500 - 9000 |
6500 - 9000 |
6500 - 9000 |
6500 - 9000 |
6500 - 9000 |
6500 - 9000 |
زاویه دید (H/V) |
140 ° / 120 درجه |
140 ° / 120 درجه |
140 ° / 120 درجه |
140 ° / 120 درجه |
140 ° / 120 درجه |
140 ° / 120 درجه |
یکنواختی درخشندگی |
≥٪ 97 |
≥٪ 97 |
≥٪ 97 |
≥٪ 97 |
≥٪ 97 |
≥٪ 97 |
The Max Power Consumption(W/M2) |
550 |
550 |
550 |
550 |
550 |
550 |
Average Power Consumption(W/M2) |
186 |
186 |
186 |
186 |
186 |
186 |
ولتاژ ورودی |
AC100 - 240 ولت |
AC100 - 240 ولت |
AC100 - 240 ولت |
AC100 - 240 ولت |
AC100 - 240 ولت |
AC100 - 240 ولت |
روش نگهداری |
جلو و عقب |
جلو و عقب |
جلو و عقب |
جلو و عقب |
جلو و عقب |
جلو و عقب |
طول عمر (ساعت) |
100000 |
100000 |
100000 |
100000 |
100000 |
100000 |
دمای کار/رطوبت |
-40 ℃ - 80 ℃ / 10٪ RH - 98٪ RH (غیر متراکم) |
-40 ℃ - 80 ℃ / 10٪ RH - 98٪ RH (غیر متراکم) |
-40 ℃ - 80 ℃ / 10٪ RH - 98٪ RH (غیر متراکم) |
-40 ℃ - 80 ℃ / 10٪ RH - 98٪ RH (غیر متراکم) |
-40 ℃ - 80 ℃ / 10٪ RH - 98٪ RH (غیر متراکم) |
-40 ℃ - 80 ℃ / 10٪ RH - 98٪ RH (غیر متراکم) |
فرکانس تازه |
3840 هرتز |
3840 هرتز |
3840 هرتز |
3840 هرتز |
3840 هرتز |
3840 هرتز |
ویژگی های کلیدی
High - Definition 3D Visuals: With high - resolution panels, it offers an unpixelated presentation, making high - definition and vivid 3D images. The high refresh rate, with a refresh frequency of ≥3840Hz, ensures smooth transitions in animations, providing a visually pleasing experience.
زوایای دید گسترده: It provides a wide viewing angle, allowing audiences from various distances and positions to have an excellent view of the content without straining their necks or eyes.
Advanced Optical Technology: Incorporates two advanced optical technologies, parallax barriers, and lenticular lenses. The parallax barriers create a 3D optical illusion through the diffraction of light, while the lenticular lens refracts light to produce a new visual effect.
مقاومت در برابر آب و هوا: Made with durable materials, it can withstand various weather conditions, including extreme heat, cold, and rain. This makes it suitable for both indoor and outdoor applications.
Real - Time Content Rendering: Enables quick and easy ad adjustments. You can change the ad display on the screen in one click, saving time and cost.
اپلیکیشنها
تبلیغات: Ideal for outdoor billboards, shopping malls, airports, and other high - traffic areas. Its eye - catching 3D effects can significantly increase brand exposure and attract more customers.
سرگرمی: Used in cinemas, theme parks, and concert venues to provide a more immersive and exciting visual experience for audiences.
Cultural and Art Exhibitions: Helps to display artworks, historical artifacts, and cultural content in a more vivid and engaging way, enhancing the visitor experience.
ارائه های شرکتی: Can be used in corporate showrooms, conferences, and events to showcase products and services in a unique and memorable manner.
در بازار جهانی کنونی، که در آن تقاضا برای راه حل های نمایشگر نوآورانه و جلب توجه در حال افزایش است، صفحه نمایش LED سه بعدی چشم برهنه ما به عنوان یک انتخاب درجه یک برجسته است. این نه تنها نیازهای صنایع مختلف را برآورده می کند، بلکه استاندارد جدیدی برای فناوری نمایش بصری ایجاد می کند.
